Longboy Replacement Parts
SKU: Silky Fox | SF-366-36
Key Features
- 17 individual Longboy replacement parts
- Ref numbers match the exploded parts diagram
- Blade, cover set, poles, stopper buttons and fixings
- Choose the exact part from the Part option
- Regular price
- $57.00
- Sale price
- $57.00 $57.00 Ex VAT
- Regular price
-
Saturday delivery (), £13.99 ex VAT
Seaton Burn, Newcastle upon Tyne,
Tyne and Wear, NE13 6DA
Free Delivery Over £75 *
Worldwide Shipping from the UK
Trusted UK Arborist Retailer
30-Day Easy Returns
Product information & specifications
Silky Longboy Pole Saw Replacement Parts
Keep your Silky Longboy 360 pole saw working like new by replacing only the part that has worn or broken. Choose from 17 individual parts, from the 360 blade and cover set to the telescopic poles, stopper button set, belt clip and fixings. Reference numbers match the exploded parts diagram so you can pick the exact part.
Silky is a Japanese precision saw brand with a long-standing reputation among professional arborists. Gustharts is an authorised Silky Fox dealer.
Check before ordering: match the Ref number on the parts diagram to the option you select. Part codes are listed in the table below and on the product page.
Two sizes: the cramp housing/stopper set comes in small (Ref 15A) and large (Ref 15B). Check the diagram against your saw before ordering.
Longboy Parts Guide
Select your part from the Part option. Poles run from the upper section (Ref 20A) to the lower section (Ref 20C), and the Longboy complete head is available for a full head replacement.
| Ref | Part | Part Code |
|---|---|---|
| 1 | Blade Longboy 360 | SF-366-36 |
| 2 | Belt Clip | SF-KZSI639000 |
| 3 | Holder Set | SF-KZSI36509 |
| 4 | Blade Cover Set | SF-KZSI3650041 |
| 5 | Blade Fixing Bolt Set | SF-KZSI36501 |
| 6 | Blade Fixing Pipe Assy | SF-KZSI3650051 |
| 7 | Bolt Set | SF-KZSI36503 |
| 8-9-10 | Stopper Button Set | SF-KZSI36504 |
| 15A | Cramp Housing/Stopper Set (S) Assy | SF-KZSI36505 |
| 15B | Cramp Housing/Stopper Set (L) Assy | SF-KZSI36506 |
| 16 | Bracket Assy H Longboy | SF-KZSI36507 |
| 17 | Strap | SF-KZSI3700420 |
| 19 | Rubber Grip Tape | SF-KZSI3650401 |
| 20A | Upper Pole Longboy | SF-KZSI3650031 |
| 20B | Middle Pole Longboy | SF-KZSI3650032 |
| 20C | Lower Pole Longboy | SF-KZSI3650033 |
| - | Longboy Complete Head | SF-366-36CMP |
Why Buy Individual Parts?
A worn stopper button, a lost bolt or a damaged pole section does not mean a new pole saw. Replacing just the failed part keeps a well-built Longboy in service for far longer and costs a fraction of a new unit.
Often Replaced Alongside
Often replaced alongside: the Longboy Pole Saw Replacement Blade and the Longboy Folding Telescopic Pole Pruner Saw.
Also Known As
Also searched for as: Silky Longboy spare parts, Longboy 360 parts, Longboy replacement parts, Silky pole saw spares, Longboy pole saw pole sections.
FAQs
How do I find the right part number?
Use the Ref number on the exploded parts diagram, then select the matching option from the Part list. Each option shows its Ref and name.
Which pole section do I need?
Ref 20A is the upper pole, 20B the middle pole and 20C the lower pole. Check the diagram against your saw to see which section is damaged.
What is the difference between Ref 15A and 15B?
Both are cramp housing/stopper set assemblies: 15A is the small (S) size and 15B the large (L). Check the diagram against your saw to pick the matching size.
Can I replace the whole saw head?
Yes. The Longboy Complete Head replaces the blade and head assembly in one go. For a worn blade only, choose Ref 1.
Are these parts for the Longboy only?
This listing covers the Longboy 360 parts diagram.
Silky Longboy Pole Saw Replacement Parts
Keep your Silky Longboy 360 pole saw working like new by replacing only the part that has worn or broken. Choose from 17 individual parts, from the 360 blade and cover set to the telescopic poles, stopper button set, belt clip and fixings. Reference numbers match the exploded parts diagram so you can pick the exact part.
Silky is a Japanese precision saw brand with a long-standing reputation among professional arborists. Gustharts is an authorised Silky Fox dealer.
Check before ordering: match the Ref number on the parts diagram to the option you select. Part codes are listed in the table below and on the product page.
Two sizes: the cramp housing/stopper set comes in small (Ref 15A) and large (Ref 15B). Check the diagram against your saw before ordering.
Longboy Parts Guide
Select your part from the Part option. Poles run from the upper section (Ref 20A) to the lower section (Ref 20C), and the Longboy complete head is available for a full head replacement.
| Ref | Part | Part Code |
|---|---|---|
| 1 | Blade Longboy 360 | SF-366-36 |
| 2 | Belt Clip | SF-KZSI639000 |
| 3 | Holder Set | SF-KZSI36509 |
| 4 | Blade Cover Set | SF-KZSI3650041 |
| 5 | Blade Fixing Bolt Set | SF-KZSI36501 |
| 6 | Blade Fixing Pipe Assy | SF-KZSI3650051 |
| 7 | Bolt Set | SF-KZSI36503 |
| 8-9-10 | Stopper Button Set | SF-KZSI36504 |
| 15A | Cramp Housing/Stopper Set (S) Assy | SF-KZSI36505 |
| 15B | Cramp Housing/Stopper Set (L) Assy | SF-KZSI36506 |
| 16 | Bracket Assy H Longboy | SF-KZSI36507 |
| 17 | Strap | SF-KZSI3700420 |
| 19 | Rubber Grip Tape | SF-KZSI3650401 |
| 20A | Upper Pole Longboy | SF-KZSI3650031 |
| 20B | Middle Pole Longboy | SF-KZSI3650032 |
| 20C | Lower Pole Longboy | SF-KZSI3650033 |
| - | Longboy Complete Head | SF-366-36CMP |
Why Buy Individual Parts?
A worn stopper button, a lost bolt or a damaged pole section does not mean a new pole saw. Replacing just the failed part keeps a well-built Longboy in service for far longer and costs a fraction of a new unit.
Often Replaced Alongside
Often replaced alongside: the Longboy Pole Saw Replacement Blade and the Longboy Folding Telescopic Pole Pruner Saw.
Also Known As
Also searched for as: Silky Longboy spare parts, Longboy 360 parts, Longboy replacement parts, Silky pole saw spares, Longboy pole saw pole sections.
FAQs
How do I find the right part number?
Use the Ref number on the exploded parts diagram, then select the matching option from the Part list. Each option shows its Ref and name.
Which pole section do I need?
Ref 20A is the upper pole, 20B the middle pole and 20C the lower pole. Check the diagram against your saw to see which section is damaged.
What is the difference between Ref 15A and 15B?
Both are cramp housing/stopper set assemblies: 15A is the small (S) size and 15B the large (L). Check the diagram against your saw to pick the matching size.
Can I replace the whole saw head?
Yes. The Longboy Complete Head replaces the blade and head assembly in one go. For a worn blade only, choose Ref 1.
Are these parts for the Longboy only?
This listing covers the Longboy 360 parts diagram.
